Working Principle

1. Loading & Conveying: Dirty crates are loaded manually or via an automatic conveyor (optional), and transported through the cleaning tunnel at a controllable speed by a chain-driven conveyor or stainless steel mesh belt, ensuring stable and smooth transfer without jamming or damage to crates.
2. Pre-Wash Stage: Recycled water is sprayed at high flow to remove loose debris, large particles, and surface dust from crates. This stage softens stubborn residues (such as food scraps and oil stains) while reducing fresh water consumption, laying the foundation for thorough cleaning in subsequent stages. The water in this stage is filtered and recirculated to achieve resource conservation.
3. Main Wash Stage: High-pressure sprays (0.2-0.7MPa) of heated water (50-85℃ adjustable) mixed with food-grade detergent are applied to crates from multiple angles. Rotatable nozzles target all surfaces of crates—top, bottom, sides, and inner corners—effectively breaking down fats, oils, proteins, and stubborn stains that manual cleaning cannot remove. The detergent concentration is precisely controlled to ensure optimal cleaning effect while avoiding waste.
4. Rinse & Sanitizing Stage: After the main wash, crates pass through the rinse section, where clean heated water (or pure water for high-demand scenarios) removes residual detergent and dirt. For industries with strict hygiene requirements (such as food and pharmaceutical), an optional sanitizing rinse is available, which sprays food-grade disinfectant to eliminate bacteria, mold, and allergens, ensuring crates meet HACCP, FDA, and EU hygiene standards.
5. Drying (Optional): An optional high-efficiency air-drying system (electric or steam heating) blows cold or hot air from all sides to quickly remove surface moisture from crates, reducing crate turnover time and preventing secondary contamination. This stage is especially suitable for industries that require immediate reuse of crates, such as cold chain logistics and food processing.

Applications

• Food & Beverage Industry: Cleaning of crates used for fruits, vegetables, dairy products, meat, bakery products, and beverages. It effectively removes food residues, oil stains, and bacteria, ensuring food safety during storage and transportation. Applicable to fresh produce packhouses, dairy facilities, meat processing plants, and beverage factories.
• Agriculture & Horticulture: Cleaning of crates for agricultural products such as vegetables, fruits, and flowers, removing soil, pesticides, and dust, extending the freshness of agricultural products and facilitating subsequent storage and transportation.
• Logistics & Distribution: Cleaning of turnover crates used in warehouses, logistics hubs, and cold chain logistics. It solves the problem of cross-contamination caused by repeated use of crates, ensuring the safety of goods during transportation and improving logistics efficiency.
• Pharmaceutical & Healthcare Industry: Cleaning of crates for medical supplies, drugs, and medical devices. It meets strict hygiene standards, removes dust and pollutants, and avoids cross-contamination, ensuring the safety of medical products.
• Other Industries: Also applicable to the chemical industry (cleaning crates for chemical raw materials), automotive industry (cleaning crates for auto parts), catering industry (cleaning turnover baskets), and aquaculture industry (cleaning fish and seafood crates).

Product Advantages

1. Superior Hygiene & Compliance: The multi-stage cleaning and sanitizing process ensures that crates are free from bacteria, mold, and residues, fully complying with HACCP, FDA, and EU hygiene standards. The entire machine is made of SUS304 (or SUS316 optional) stainless steel, which is corrosion-resistant, rust-proof, easy to clean, and meets food-grade and pharmaceutical-grade hygiene requirements, avoiding secondary contamination.
2. High Efficiency & Labor Savings: The automatic operation replaces repetitive manual cleaning, reducing labor costs by 60%-80%. The cleaning capacity can be customized from 100 to 2000 crates per hour, which is 10-15 times that of manual cleaning. The adjustable conveyor speed (3-15 m/min) can be matched with your production line to achieve seamless connection and improve overall operational efficiency.
3. Energy & Water Saving: Equipped with a double-layer water circulation and filtration system, the water reuse rate reaches 80%以上, reducing water consumption to 0.5-0.6L per crate. The energy-efficient heating system (electric or gas heating optional) with precise temperature control reduces energy consumption by 30% compared with traditional equipment. The detergent dosing control system avoids excessive use of detergent, further reducing operating costs and achieving environmental protection goals.
4. Versatility & Customization: Suitable for cleaning various types and sizes of crates, baskets, trays, and pallets, including plastic, metal, and wooden crates. We provide free customized solutions based on your specific needs, such as adjusting the machine size, adding a drying system, dual-channel cleaning, or fully automatic palletizers, to meet the unique requirements of different industries and scenarios.
5. Durability & Easy Maintenance: The machine body is made of 3mm thick SUS304 stainless steel, with wear-resistant, corrosion-resistant, and impact-resistant properties, ensuring a service life of 8-10 years. The modular design and removable filters make daily maintenance and part replacement easy, reducing downtime. The intelligent control panel with built-in under-voltage protection ensures stable operation and easy operation.

6. Safe & User-Friendly: Equipped with safety protection devices (emergency stop button, protective cover, and overload protection) to avoid operational accidents. The PLC intelligent control panel allows one-click operation, with clear display of temperature, water pressure, and cleaning time, and can store multiple cleaning parameters for different crates, making operation simple even for unskilled workers. A viewing window is also available for real-time monitoring of the cleaning process.

   FAQ (Frequently Asked Questions)

   1. Can the machine be customized for different crate sizes and types? Yes, absolutely. Our Crate Washing Machine supports all sizes and types of crates (plastic, metal, wooden, etc.). We will provide free customized solutions based on your specific crate dimensions, contamination level, cleaning capacity, and other needs, such as adjusting the conveyor width, nozzle angle, and machine size. We can also customize special functions like dual-channel cleaning or automatic palletizing according to your production line requirements.
   2. How long does it take to install and debug the machine? The standard installation and debugging time is 3-5 working days. We will send professional engineers to your site (if required) to guide installation, debug the machine, and train your operators to ensure the machine can operate normally. For small-sized machines, we also provide detailed installation instructions and online guidance to help you complete installation quickly.
   3. What is the service life of the machine? How to maintain it daily? The service life of the machine is 8-10 years under normal use and proper maintenance. Daily maintenance is simple: clean the filter regularly (once a day), check the water level and detergent concentration, and wipe the machine surface with a clean cloth. We will provide a detailed maintenance manual, and our after-sales team will remind you of regular maintenance items and provide technical support at any time.
   4. Does the machine require special detergents? Can I use ordinary detergents? We recommend using food-grade, low-foam detergents that are non-toxic, environmentally friendly, and compatible with the machine’s materials. Ordinary detergents may produce excessive foam, block the nozzles, or corrode the machine body, affecting the cleaning effect and service life. We can provide recommendations for suitable detergents or supply matching detergents according to your needs.
   5. Is the machine easy to operate? Do I need professional training? The machine adopts a PLC intelligent control panel with a humanized design, one-click operation, and clear display of all parameters (temperature, water pressure, cleaning time, etc.). It is very easy to operate, and general workers can master it after 1-2 hours of training. We provide free online or on-site training, and a detailed operation manual is included in the package.
   6. What if the machine breaks down? How is the after-sales service? We provide 7×24-hour online technical support. If the machine breaks down, you can contact our after-sales team at any time, and we will respond within 2 hours to provide solutions. For minor faults, we can solve them through online guidance; for major faults, we will send professional engineers to your site within 72 hours (depending on your location) to repair the machine. The machine has a one-year warranty, and we provide lifelong maintenance services.
   7. Can the machine achieve drying effect? How long does it take to dry the crates? Yes, we provide an optional high-efficiency air-drying system. The drying time depends on the crate size and moisture content, usually 30-60 seconds. The drying effect can reach a surface moisture content of less than 5%, ensuring that the crates can be reused immediately without secondary contamination. You can choose whether to add the drying system according to your actual needs.
   8. Does the machine meet international hygiene standards? Can it be used in food and pharmaceutical industries? Yes. The entire machine is made of SUS304 stainless steel, which meets food-grade and pharmaceutical-grade hygiene requirements. The multi-stage cleaning and sanitizing process can effectively eliminate bacteria, mold, and allergens, fully complying with HACCP, FDA, and EU hygiene standards. It is widely used in food, beverage, and pharmaceutical industries around the world.

   Packaging Details

   To ensure the machine is not damaged during transportation, we adopt professional packaging standards, suitable for sea, land, and air transportation:

   1. Inner Packaging: The entire machine is wrapped with moisture-proof, dust-proof PE film to prevent rust and dust during transportation. Vulnerable parts (such as nozzles, control panel, and conveyor chain) are wrapped with foam and plastic film separately to avoid collision damage.
   2. Outer Packaging: Standard export plywood boxes (fumigation-free, compliant with international export standards) are used to ensure the machine is protected from impact, extrusion, and moisture during long-distance transportation. For large-sized machines, we can also use wooden frames or container packaging according to your needs.
   3. Packaging Accessories: All accessories (such as spare nozzles, filters, operation manual, maintenance manual, and tools) are packed in a separate waterproof box and placed in the outer packaging to avoid loss. We also attach a transportation label and a fragile label to remind the logistics company to handle it with care.

   Note: We can customize the packaging according to your special requirements (such as branding, packaging materials, etc.) to meet your export or transportation needs.

   After-Sales Service

   We are committed to providing professional, timely, and comprehensive after-sales service to ensure your machine operates stably and brings continuous value to your business. Our after-sales service includes the following items:

   1. Warranty Service: The machine enjoys a 1-year free warranty from the date of installation and commissioning. During the warranty period, we will provide free replacement of damaged parts (excluding wearing parts such as nozzles and filters) and free on-site maintenance if there are quality problems caused by the machine itself. Wearing parts are provided at cost price during and after the warranty period.
   2. Technical Support: 7×24-hour online technical support (email, phone, video call) is provided. Our professional after-sales team will respond within 2 hours to solve your operation and maintenance problems. We also provide free technical consultation for the entire service life of the machine, including production line matching, parameter adjustment, and efficiency improvement.
   3. On-Site Service: If the machine has major faults that cannot be solved online, we will send professional engineers to your site within 72 hours (depending on your location) to repair and debug the machine. The round-trip transportation and accommodation costs of engineers are borne by us during the warranty period; after the warranty period, we only charge a reasonable service fee and part costs.
   4. Training Service: Free on-site or online training is provided for your operators and maintenance personnel, including machine operation, daily maintenance, fault diagnosis, and part replacement. We ensure that your team can proficiently operate and maintain the machine to reduce downtime.
   5. Spare Parts Supply: We have a complete spare parts warehouse, and all spare parts are available in stock. We can deliver spare parts to your location quickly (by express or air freight) to ensure that the machine can be repaired in time and reduce losses caused by downtime. We provide spare parts at preferential prices for long-term cooperative customers.
   6. Regular Follow-Up: After the machine is put into use, we will conduct regular follow-up (1 month, 3 months, 6 months, 1 year) to understand the operation status of the machine, collect your feedback, and provide professional suggestions for maintenance and efficiency improvement, helping you maximize the value of the machine.

   Why Choose Us?

   We are a professional manufacturer of industrial cleaning equipment with years of experience in R&D, production, and export of Crate Washing Machines. Our products are sold to more than 50 countries and regions around the world, and have been highly recognized by customers in food, logistics, agriculture, and other industries. Choosing us means choosing high-quality products, customized solutions, and reliable after-sales service. We are committed to becoming your long-term partner in improving operational efficiency and ensuring hygiene safety.

   Contact us now to get a free customized quote and detailed product brochure! Our professional team will provide you with one-stop solutions tailored to your needs
